Model Description


Follow the MAX

Nothing beats a Yamaha Sport Scooter when you’re looking for a smart, stylish and efficient way to get into the city. And with its dynamic body design, smartphone connectivity and Garmin enabled navigation compatibility, the XMAX 125 Tech MAX is built to deliver a premium urban commuting experience.

The hugely popular XMAX 125 Tech MAX is equipped with a state of the art 4.2-inch full colour TFT instruments with a multi-theme infotainment screen that enables smartphone connectivity. It’s easy to receive messages and emails, select music and much more – and a new Garmin navigation system makes the journey to work even easier.

The tight and dynamic angular body design with its X-shaped front lighting gives the XMAX 125 Tech MAX a sporty look that really stands out in the crowd. And this class-leading 125cc commuter also features exclusive colours as well as aluminium footplates, a special finish on body parts and a leather-style seat cover..

Colours

– Dark Magma

– Tech Black

Model Specification


  • Engine

    Engine Type

    4-stroke, Liquid-cooled, SOHC, 4-valves, Single cylinder

    Displacement

    125 cc

    Bore x Stroke

    52.0 × 58.7 mm

    Compression Ratio

    11.2:1

    Maximum Power

    9.0 kW @ 8,000 rpm

    Maximum Torque

    11.2 Nm @ 6,000 rpm

    Starter System

    Electric

    Transmission

    V-Belt Automatic

    Lubrication System

    Wet sump

    Clutch Type

    Ignition System

    TCI

    Final Transmission

    Fuel Consumption

    Start & Stop on: 2.3 l / 100 km, Start & Stop off: 2.4 l / 100 km

    CO2 Emissions

    Start & Stop on: 54 g / km, Start & Stop off: 56 g / km

    Fuel System

    Fuel Injection

  • Dimensions

    Oil Tank Capacity

    Fuel Tank Capacity

    13.2 l

    Length (mm)

    2,180 mm

    Width (mm)

    795 mm

    Height (mm)

    1,410 mm - 1,460 mm (adjustable windscreen)

    Wheel Base (mm)

    1,570 mm

    Weight (kg)

    167 kg

    Ground Clearance (mm)

    140 mm

  • Frame

    Front Tyre

    120/70-15

    Rear Tyre

    140/70-14

    Frame

    Caster Angle

    Trail

    Front Suspension System

    Telescopic forks

    Rear Suspension System

    Unit Swing

    Front Travel

    110 mm

    Rear Travel

    90 mm

    Front Brake

    Hydraulic single disc, Ø267 mm (ABS)

    Rear Brake

    Hydraulic single disc, Ø245 mm (ABS)
